Process Viewing
Visual inspection on transfer and process lines.
Hygienic Components
Sanitary Sight Glasses for Visual Process Inspection.
Sight glasses provide visual inspection points for hygienic process lines, tanks and equipment packages.
304 / 316LTri-ClampInspectionRFQ Ready
Applications
Visual inspection for process confidence.
Sight glasses are used where operators need visual confirmation of product, flow or cleaning activity.
Cleaning Verification
Used in hygienic process and CIP-adjacent systems.
Tank / Skid Integration
Sight glass requirements for tanks, vessels and skids.
Sizes & Dimensions
Sight glass configurations.
In-line tubular type for installation in pipework, or flanged tank-mounted type for vessel viewing. Borosilicate glass with 316L body.
| Nominal | DN | OD (mm) | Glass Dia (mm) | Length (mm) | Weight (kg) |
|---|---|---|---|---|---|
| ½" | DN15 | 50.5 | 25 | 80 | 0.6 |
| 1" | DN25 | 50.5 | 38 | 80 | 0.8 |
| 1½" | DN40 | 64.0 | 50 | 100 | 1.5 |
| 2" | DN50 | 77.5 | 63 | 120 | 2.4 |
| 2½" | DN65 | 91.0 | 80 | 140 | 3.5 |
| 3" | DN80 | 104.0 | 100 | 160 | 5.0 |
| 4" | DN100 | 119.0 | 125 | 180 | 7.5 |
Operating Conditions
Pressure-temperature rating for sanitary sight glasses.
Borosilicate glass is rated for moderate pressure and thermal shock. Avoid sudden temperature changes greater than 150°C.
Service Conditions
- Max working pressure: 10 bar
- Max test pressure: 15 bar
- Temperature range: –10°C to +180°C
- Thermal shock: Δ150°C max
- Glass material: Borosilicate 3.3
- Body material: 316L SS
Actual ratings depend on size, material and operating conditions. Confirm via RFQ for project-specific requirements.
Standards & Compliance
Built to recognized sanitary and pressure standards.
Full documentation packages available including MTR, 3.1 certificates, surface roughness reports and pressure test records.
3-A 09-11
3-A Sight Glasses
Sanitary sight glasses and fittings standard.
DIN 7080
Round Sight Glasses
German standard for round sight glasses.
DIN 8902
Toughened Glasses
German standard for toughened sight glasses.
EHEDG
Hygienic Equipment Design
European hygienic engineering and design certification.
FDA 21 CFR
FDA 21 CFR 177
Food contact materials compliance for seats and seals.
EC 1935/2004
Food Contact
EU regulation on food-contact materials.
Product Variants
Sight Glass configurations for different process roles.
Multiple variants available to match your application requirements. Browse related products for complete process line coverage.
Inline Tubular
In-pipe sight glass for visual inspection of flow, color and clarity.
Request quote →With Illumination
Integrated LED light (24V DC) for enhanced viewing in dark process.
Request quote →Technical Overview
Typical sight glass RFQ fields.
Specify connection, size, material and seal/glass requirements.
| Requirement | Typical Information Needed |
|---|---|
| Product Type | Sanitary sight glass |
| Material Grade | 304 / 316L stainless steel |
| Connection | Tri-clamp, weld or threaded by RFQ |
| Seal / Glass | Seal material and viewing glass requirements by RFQ |
| Documentation | MTR / QC by RFQ |
Engineering RFQ
Prepare a sight glass RFQ.
Include size, connection, material, seal, glass requirement, quantity and documentation expectations.
- Size / connection / material grade
- Quantity and target lead time
- Drawing, BOM or existing part reference
- Documentation and finish requirements
Documentation by RFQ
Material certificates, finish notes, inspection requirements, heat traceability and supplier documentation can be included in the quotation package.
Have a sight glass requirement?
Send size, connection, material, seal and quantity requirements.
Engineering Documentation
Technical Datasheet Available
Download the product datasheet for technical specifications, dimensional references, material data, applicable standards and RFQ guidance. Suitable for procurement, engineering review and project documentation.
Common Questions
Frequently asked questions about sanitary sight glasses.
Engineering and procurement questions we hear most often. For project-specific guidance, send your application details via RFQ.
What is sight glass used for?
Visual confirmation of process flow, fluid level, foam formation, color changes, particulate presence, and CIP cycle progress.
Strategic placement: after pumps to confirm priming, on tank outlets, on CIP return lines, after filters, and at sample points.
How fragile is borosilicate glass?
Borosilicate is durable but can break from thermal shock (>150°C change) or excessive bolt torque. Standard pressure rating provides good safety margin.
Always inspect for cracks/chips on assembly. Use cushion gasket (PTFE) between glass and metal. Tighten bolts gradually in cross pattern to specified torque.
Can sight glasses handle steam?
For SIP cycles, gradual warm-up required (no rapid steam injection). Standard sight glasses rated for 180°C continuous, 200°C peak.
For frequent SIP, specify toughened glass (DIN 8902) for better thermal shock resistance. Provide cycle temperature/frequency for selection.
What thermal shock limit applies?
Standard borosilicate: 150°C temperature change. Toughened: 250°C change. Exceeding these limits causes thermal stress fracture.
For CIP/SIP cycles, control temperature ramp rates. Pre-warm system before introducing hot CIP solutions.
Are there options with LED lighting?
Yes — integrated LED illumination (24V DC) available for enhanced viewing in dark processes or for video monitoring.
IP65/IP67 rated for washdown environments. ATEX-certified options for hazardous areas. Provide voltage and certification needs with RFQ.
What is the wiper option?
A mechanical wiper inside the sight glass clears product film/deposits for clear viewing. Useful for viscous, opaque or filming media.
Wiper operated manually via external knob. Constructed of PTFE or silicone for hygienic compatibility. Specify wiper material based on media.
What documentation is provided?
Standard: 3.1 MTR for body, glass certification, FDA compliance for seals, pressure test certificate.
Optional: thermal cycle test report, ATEX certification (LED option), full BPE package for pharmaceutical applications.
